SCA 1.03
SCA 1.03 is equipped with a lower feeding roller controlled by a brushless servo motor and can apply tapes from 12 to 20 mm. width, by changing the guides. SCA 1.03 is perfect to apply reinforcing tape on boot uppers and to avoid creases or the stretching of the tape.
-
Mô tả
-
Hướng dẫn mua hàng
Seam Pressing and Taping Machine
SCA 1.03 is equipped with a lower feeding roller controlled by a brushless servo motor and can apply tapes from 12 to 20 mm. width, by changing the guides. SCA 1.03 is perfect to apply reinforcing tape on boot uppers and to avoid creases or the stretching of the tape. The cutting device is able to cut any tape and is controlled by an adjustable sensor or by a timer to execute very short piece of work. To operate this machine is very easy, as its guide device keeps the upper always in the right position.
Technical Data
Adjustable speed from 0 to 14 mt/min.
Tape guide mm. 16
Absorbed power max. 0,3 kW
Power supply single-phase 230 Volt 50/60 Hz
Optional
Tape guides mm. 12 – 14 –18 – 20 mm.
Machine dimensions cm. 110 x 55 x 140 h.
Machine weight 113 kg
